FEATURES
- High strength, suitable for installing at telecom room
- Modular design, easy for installation
- Reinforced pedestal (L or U-shape) design
- Enameled painting, rustproof treatment
- Many choices of color
- Aluminum alloy material: lightweight, stable and durable
- Iron material: solid, durable and economical
- Customized design is available
Model | Total Height | Inner Height | Standard Unit | Width |
TLC-15U Aluminum | 797 | 667 | 15U | 19-inche (Inner Width 451) (Outer Width 535)
23-inche (Inner Width 553) (Outer Width 636) |
TLC-24U Aluminum | 1197 | 1067 | 24U | |
TLC-30U Aluminum | 1464 | 1334 | 30U | |
TLC-36U Aluminum | 1730 | 1600 | 36U | |
TLC-41U Aluminum | 1953 | 1823 | 41U | |
TLC-42U Aluminum | 1997 | 1867 | 42U | |
TLC-45U Aluminum | 2130 | 2000 | 45U | |
TLC-58U Aluminum | 2708 | 2578 | 58U | |
TLC-6’6” Iron | 1982 | 1864 | 42U | |
TLC-7’ Iron | 2315 | 2010 | 45U | |
TLC-9’ Iron | 2745 | 2620 | 58U | |
TLC-11’6” Iron | 3505 | 3380 | 76U |
Unit: mm
1U=1.75 inches=44.45mm
